Specifications
Key Specifications
| Feature | Specification |
|---|---|
| Throughput | 240 tests/hour |
| Sample Volume | As low as 2.0 μL/test (Micropipette Tech) |
| Sample Capacity | Up to 90 positions (continuous loading with barcode) |
| Reagent Capacity | 90 positions (2°C–12°C cooling, barcode reader) |
| Reaction Cups | 80 positions |
| STAT Handling | Dedicated STAT channel |
Core Technologies
1. Integrated ISE Unit
-
Direct measurement of Na⁺, K⁺, Cl⁻, pH, iCa²⁺ (no separate module required).
2. Micropipette Technology
-
Ultra-low sample consumption (2.0 μL/test), reducing sample volume demands.
3. Advanced Photometry System
-
Holographic concavity flat-field grating with rear spectroscopy.
-
16-wavelength simultaneous detection (340–800 nm).
-
Wide absorbance linear range + high resolution.
4. Solid-Phase Temperature Control
-
Stable 37°C incubation (constant for all 80 reaction cups).
-
Real-time monitoring with alerts for deviations.
5. Smart Reagent Management
-
Reagent barcode scanning + real-time inventory tracking (tests remaining displayed).
-
Auto-replace function for high-volume testing.
Automation & Workflow
-
Continuous Sample Loading: No-interrupt operation during loading/unloading.
-
Flexible Testing Modes: Batch, random access, or STAT priority.
-
4-Step Washer System:
-
Pre-heated pure water + auto-diluted detergent.
-
Automated cell blank check after washing.
-
-
Touchscreen OS:
-
Real-time monitoring + LIS connectivity (Ethernet/bidirectional).
-
Operational Advantages
-
Reduced Sample Volume: Ideal for pediatrics/low-sample scenarios.
-
STAT Priority: Urgent tests processed without disrupting batches.
-
Reagent Efficiency: Auto-replace minimizes downtime during high throughput.
-
Quality Assurance: Temperature alerts + automated cuvette blank checks.
